4 Inch100MM Handheld Precision Digital Pressure Gauge

• Product Description

4 Inch100MM Handheld Precision Digital Pressure Gauge

Digital pressure gauges include precision digital pressure gauges, handheld precision digital pressure gauges, diaphragm digital pressure gauges, benchtop precision digital pressure gauges, and failure-proof digital pressure gauges.

Precision digital pressure gauges not only solve the problem of standard pressure calibration but also better meet the comprehensive testing needs in the field. They can be used as high-accuracy calibration standards (gauges) for the calibration and verification of pressure transmitters. These portable instruments can operate on both AC and DC power, measuring current simultaneously with pressure and displaying the results on an LCD screen, and also have a 24VDC output. A microprocessor automatically compensates for zero-point drift, temperature drift, and nonlinearity, ensuring high accuracy within the instrument's operating conditions. Single-range, single-function precision digital pressure gauges can replace traditional precision pointer pressure gauges.

Operating Environment

a. Temperature: (0～50)℃ (Operating temperature range to ensure accuracy)

b. Relative Humidity: <95%

c. Power Supply: Rechargeable battery or external adapter. The battery can be charged via the adapter when low on power. A full charge allows for ten days of continuous operation.

Technical Parameters

Pressure Range: -100kPa ～ 2kPa ～ 60MPa (Other pressure ranges can be customized according to user needs)

Accuracy (Precision): ±0.4%F.S; ±0.25%F.S; ±0.16%F.S; ±0.1%F.S; ±0.05%F.S; ±0.025%F.S; ±0.02%F.S (partial range)

Product Features

• Low power consumption, high accuracy, high-definition digital LCD display;
• Small size, easy to operate, convenient for on-site calibration and precision pressure measurement;
• Intelligent calibration, linear correction, two-second magnetic pen zeroing;
• LCD display with dynamic pressure value display function, intuitively showing pressure percentage;
• Pressure units: mmH2O, mmHg, psi, kPa, MPa, Pa, mbar, bar (up to ten pressure units optional)
• Displays online pressure measurement dynamic change curves, peak recording function (optional);
• Various additional functions, such as RS486 interface output, 4-20mA output, 0~5V output, real-time data communication output, USB interface, storage function (optional);
• Power supply: Built-in AA lithium battery for 5-7 years; or rechargeable lithium battery (with charger); or AC 220V power supply.

Product Advantages

1. This precision digital pressure gauge is a portable instrument that can operate on both AC and DC power.

2. The high-performance microprocessor continuously corrects the instrument's performance and technical specifications, ensuring consistent accuracy over extended periods and across a wide temperature range.

3. Low power consumption. It uses imported high-energy nickel-metal hydride batteries, guaranteeing long-term operation.

4. Constant current charging with overcharge and undervoltage automatic shutdown and protection functions prevent battery damage due to overcharging or undervoltage, extending battery life.

5. Low-power undervoltage automatic protection ensures the battery will not be damaged by undervoltage even if the instrument is left on for extended periods due to operator error.

6. The instrument offers a wide range of measuring functions, providing multiple uses in one instrument.

7. The software is feature-rich, simple, and intuitive to use.

8. It uses a membrane panel touch switch with a novel design and long button life.

9. Full-scale calibration can be performed directly on the panel.

Technical Specifications

1. Measuring Range: -95kPa~60MPa (various ranges)

2. Resolution: Pressure: Min 1Pa, Current: Min 1μA

3. Widescreen, 6-digit large characters, clear and intuitive

4. Accuracy: 0.05%F˙S, Current: 0.05%±1d

5. DC Output: 24V·DC

6. Ambient Temperature: 5 ~ 50℃

7. DC Operating Time: ≥40 hours

8. Display: 4 1/2 LCD, 5 1/2 LCD

9. Relative Humidity: ≤80%RH

10. Overload Capacity: 1.2 ~ 1.5 times the upper limit of the measuring range

11. Housing Diameter: 110mm

12. Weight: 1kg

13. Power Supply: External charger 220VAC 50Hz 3VA

14. Mounting Connector: M20X1.5

• Applications

Widely used in power, metallurgy, petroleum, chemical, and metrology systems for measurement and research in laboratories and on-site. It can provide measurement services for calibrating pressure (differential pressure) transmitters, precision pressure gauges, general pressure gauges, sphygmomanometers, pressure reducing valves, and other instruments.
